Delfield N8717-D 1-Pan Drop-In Hot Food Well 18" - Holds (1) 12" x 20" Pan - 120v
Delfield | SKU:
130127
Loading...
$2,044.58
Unit price /
Unavailable
Couldn't load pickup availability
In stock
SHIPS IN 1-3 BUSINESS DAYS
Corpus Christi Store: 0 in stock
McAllen Store: 1 in stock
Description
Description
Delfield N8717-D Drop-In Hot Food Well
The top is constructed of 18 gauge stainless steel. The wells are depressed slightly into the top in order to hold in condensation. It has standard 1/2" stainless steel drains with a non-marring press fit top gasket.
It must be hard wired in the field.
For wet and dry operation, the 11.87" x 19.87" single hot food wells are manifolded together, standard to one main gate valve. This unit is insulated on all sides with 1" of fiberglass and the bottom to have 2" of fiberfrax blanket insulation.
It has individual infinate temperature controls standard wired to one main control panel with 4" of conduit and wire.
Manufacturer Details:
Drop-In Hot Food Well Unit, Electric, individual pans, wet/dry type with drain & manifold, 1-pan size for 12" x 20" pan, individual infinite temperature controls, stainless steel top & wells, galvanized outer liner (16-7/8" x 25" cutout required)
Delfield N8717-D Drop-In Hot Food Well
The top is constructed of 18 gauge stainless steel. The wells are depressed slightly into the top in order to hold in condensation. It has standard 1/2" stainless steel drains with a non-marring press fit top gasket.
It must be hard wired in the field.
For wet and dry operation, the 11.87" x 19.87" single hot food wells are manifolded together, standard to one main gate valve. This unit is insulated on all sides with 1" of fiberglass and the bottom to have 2" of fiberfrax blanket insulation.
It has individual infinate temperature controls standard wired to one main control panel with 4" of conduit and wire.
Manufacturer Details:
Drop-In Hot Food Well Unit, Electric, individual pans, wet/dry type with drain & manifold, 1-pan size for 12" x 20" pan, individual infinite temperature controls, stainless steel top & wells, galvanized outer liner (16-7/8" x 25" cutout required)
Specifications
Amps
8.3
Height
9-1/2"
Installation Type
Drop-In
Manufacturer
Delfield
Model Number
N8717-D
Sold By
1/Each
Type
Hot Food Well
Volt/Hz/Ph
120/60/1
Wattage
1000
Width
18"
Specifications
Specifications
Amps
8.3
Height
9-1/2"
Installation Type
Drop-In
Manufacturer
Delfield
Model Number
N8717-D
Sold By
1/Each
Type
Hot Food Well
Volt/Hz/Ph
120/60/1
Wattage
1000
Width
18"
