CaptiveAire DU30HFA-400-1000 High Speed Direct Drive Centrifugal Upblast Exhaust Fan 1000 CFM - 115v

CaptiveAire  |  SKU: 1124
1 7
$699.99
/ea
Ships in 1-3 business days
View your Reorder Pad list

Financing

Financing info

Description

CaptiveAire DU30HFA-1000 High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control

This cooking exhaust fan is designed for continuous operation to remove stale, grease filled air from indoor environments. It has an upblast design to direct the discharged air away from the roof or wall.

(Speed control included for single phase only)

  • Disconnect switch and 13-3/4" wheel
  • Exhaust Fan handles 1000 CFM @ -0.250" wc ESP
  • Fan runs at 1404 RPM
  • Exhaust Motor: 0.250 HP, 1 Phasec 115 V, 60Hz, 3.8 FLA, ODP (Open Drip Proof)

Flashing size needed 19-1/2" x 19-1/2"

FEATURES & BENEFITS

  • Completely enclosed drive compartment protects motor from airborne contaminants
  • Forced fresh air through the motor compartment cools motor and ensures long motor life
  • Variable Speed Control on Single Phase Units Only. (VFDs required to adjust speed for 3 phase versions)
  • Non-overloading backward inclined wheels, blades and inlets fabricated from aluminum
  • Units up to 24" nominal wheel can be wall mounted
  • Quick release latches allow for easy access to motor compartment. (Size 12 & larger)
  • Standard emergency disconnect switch (Size 12 & larger)

CaptiveAire DU30HFA-1000 High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control

This cooking exhaust fan is designed for continuous operation to remove stale, grease filled air from indoor environments. It has an upblast design to direct the discharged air away from the roof or wall.

(Speed control included for single phase only)

  • Disconnect switch and 13-3/4" wheel
  • Exhaust Fan handles 1000 CFM @ -0.250" wc ESP
  • Fan runs at 1404 RPM
  • Exhaust Motor: 0.250 HP, 1 Phasec 115 V, 60Hz, 3.8 FLA, ODP (Open Drip Proof)

Flashing size needed 19-1/2" x 19-1/2"

FEATURES & BENEFITS

  • Completely enclosed drive compartment protects motor from airborne contaminants
  • Forced fresh air through the motor compartment cools motor and ensures long motor life
  • Variable Speed Control on Single Phase Units Only. (VFDs required to adjust speed for 3 phase versions)
  • Non-overloading backward inclined wheels, blades and inlets fabricated from aluminum
  • Units up to 24" nominal wheel can be wall mounted
  • Quick release latches allow for easy access to motor compartment. (Size 12 & larger)
  • Standard emergency disconnect switch (Size 12 & larger)

Specifications
Sold By
1/Each
Manufacturer
CaptiveAire
Model Number
DU30HFA-400-1000
Width
25-1/2"
Height
25-1/4"
Base Width
21"
Style
High Speed Direct Drive Centrifugal Upblast
Type
Exhaust Fan

Resources

Video
Description

CaptiveAire DU30HFA-1000 High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control

This cooking exhaust fan is designed for continuous operation to remove stale, grease filled air from indoor environments. It has an upblast design to direct the discharged air away from the roof or wall.

(Speed control included for single phase only)

  • Disconnect switch and 13-3/4" wheel
  • Exhaust Fan handles 1000 CFM @ -0.250" wc ESP
  • Fan runs at 1404 RPM
  • Exhaust Motor: 0.250 HP, 1 Phasec 115 V, 60Hz, 3.8 FLA, ODP (Open Drip Proof)

Flashing size needed 19-1/2" x 19-1/2"

FEATURES & BENEFITS

  • Completely enclosed drive compartment protects motor from airborne contaminants
  • Forced fresh air through the motor compartment cools motor and ensures long motor life
  • Variable Speed Control on Single Phase Units Only. (VFDs required to adjust speed for 3 phase versions)
  • Non-overloading backward inclined wheels, blades and inlets fabricated from aluminum
  • Units up to 24" nominal wheel can be wall mounted
  • Quick release latches allow for easy access to motor compartment. (Size 12 & larger)
  • Standard emergency disconnect switch (Size 12 & larger)

CaptiveAire DU30HFA-1000 High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control

This cooking exhaust fan is designed for continuous operation to remove stale, grease filled air from indoor environments. It has an upblast design to direct the discharged air away from the roof or wall.

(Speed control included for single phase only)

  • Disconnect switch and 13-3/4" wheel
  • Exhaust Fan handles 1000 CFM @ -0.250" wc ESP
  • Fan runs at 1404 RPM
  • Exhaust Motor: 0.250 HP, 1 Phasec 115 V, 60Hz, 3.8 FLA, ODP (Open Drip Proof)

Flashing size needed 19-1/2" x 19-1/2"

FEATURES & BENEFITS

  • Completely enclosed drive compartment protects motor from airborne contaminants
  • Forced fresh air through the motor compartment cools motor and ensures long motor life
  • Variable Speed Control on Single Phase Units Only. (VFDs required to adjust speed for 3 phase versions)
  • Non-overloading backward inclined wheels, blades and inlets fabricated from aluminum
  • Units up to 24" nominal wheel can be wall mounted
  • Quick release latches allow for easy access to motor compartment. (Size 12 & larger)
  • Standard emergency disconnect switch (Size 12 & larger)

Specifications
Sold By
1/Each
Manufacturer
CaptiveAire
Model Number
DU30HFA-400-1000
Width
25-1/2"
Height
25-1/4"
Base Width
21"
Style
High Speed Direct Drive Centrifugal Upblast
Type
Exhaust Fan
Features
Disconnect switch and 11−3/4" Wheel
Material
Heavy-Duty Aluminum
