EconAir SC-111110MA 120V/1-Phase Electrical System Control Panel for 1 Exhaust Fan

EconAir  |  SKU: 278352
1 2
$1,847.57
/ea
In stock

SHIPS IN 1-3 BUSINESS DAYS
View your Reorder Pad list

Description

EconAir SC-111110MA 120V/1-Phase Control Panel for Exhaust Fans


Manufacturer Details:

SC-111110MA 120V 1 Phase w/ control for 1 Exhaust Fan, 1 Supply Fan, Exhaust on in Fire, Lights out in Fire, Relay On/Off with Supply Fan, Fan(s) On/Off Thermostatically Controlled. Room temperature sensor shipped loose for field installation. Includes 1 Duct Thermostat kit.

- 14x18 Stainless Steel Box. Includes latch and backplate

- Digital Prewire Lighting Relay Kit. Includes hood lighting relay & terminal blocks. Allows for up to 1400W of lighting each.

- Multi-Conductor - Single Shielded Twisted Pair Cable, 18 AWG stranded (19x30) TC conductors, plenum, FEP insulation, overall shield (100% coverage), 20 AWG stranded TC drain wire, FEP jacket. Priced per foot. For use with CORE Interlock Network, light dimming 0-10VDC reference signal, and PWM signal from ECPM03 to ECM.

- Thermistor CABLE - 18/2 AWG GREEN WHITE, plenum rated. USED for thermistor duct stat. Per Foot Price.



EconAir SC-111110MA 120V/1-Phase Control Panel for Exhaust Fans


Manufacturer Details:

SC-111110MA 120V 1 Phase w/ control for 1 Exhaust Fan, 1 Supply Fan, Exhaust on in Fire, Lights out in Fire, Relay On/Off with Supply Fan, Fan(s) On/Off Thermostatically Controlled. Room temperature sensor shipped loose for field installation. Includes 1 Duct Thermostat kit.

- 14x18 Stainless Steel Box. Includes latch and backplate

- Digital Prewire Lighting Relay Kit. Includes hood lighting relay & terminal blocks. Allows for up to 1400W of lighting each.

- Multi-Conductor - Single Shielded Twisted Pair Cable, 18 AWG stranded (19x30) TC conductors, plenum, FEP insulation, overall shield (100% coverage), 20 AWG stranded TC drain wire, FEP jacket. Priced per foot. For use with CORE Interlock Network, light dimming 0-10VDC reference signal, and PWM signal from ECPM03 to ECM.

- Thermistor CABLE - 18/2 AWG GREEN WHITE, plenum rated. USED for thermistor duct stat. Per Foot Price.



Attention CA Residents: Prop 65 Warning

Specifications
Sold By

1/Each

Manufacturer

EconAir

Model Number

SC-111110MA

Type

Control Panel

For Use With

Exahaust Fan

Specifications
Sold By

1/Each

Manufacturer

EconAir

Model Number

SC-111110MA

Type

Control Panel

For Use With

Exahaust Fan

Resources

EconAir SC-111110MA 120V/1-Phase Electrical System Control Panel for 1 Exhaust Fan

$1,847.57
View details
Description

EconAir SC-111110MA 120V/1-Phase Control Panel for Exhaust Fans


Manufacturer Details:

SC-111110MA 120V 1 Phase w/ control for 1 Exhaust Fan, 1 Supply Fan, Exhaust on in Fire, Lights out in Fire, Relay On/Off with Supply Fan, Fan(s) On/Off Thermostatically Controlled. Room temperature sensor shipped loose for field installation. Includes 1 Duct Thermostat kit.

- 14x18 Stainless Steel Box. Includes latch and backplate

- Digital Prewire Lighting Relay Kit. Includes hood lighting relay & terminal blocks. Allows for up to 1400W of lighting each.

- Multi-Conductor - Single Shielded Twisted Pair Cable, 18 AWG stranded (19x30) TC conductors, plenum, FEP insulation, overall shield (100% coverage), 20 AWG stranded TC drain wire, FEP jacket. Priced per foot. For use with CORE Interlock Network, light dimming 0-10VDC reference signal, and PWM signal from ECPM03 to ECM.

- Thermistor CABLE - 18/2 AWG GREEN WHITE, plenum rated. USED for thermistor duct stat. Per Foot Price.



Attention CA Residents: Prop 65 Warning

Specifications
Sold By

1/Each

Manufacturer

EconAir

Model Number

SC-111110MA

Type

Control Panel

For Use With

Exahaust Fan
